        晉昌盛起重索具集團,標志,logo

        LA手扳葫蘆

        Loading...

        品牌名稱:晉陽湖

        LA型的產品介紹:高性能、高安全性又充滿了靈性,巧奪天工,自成一派,讓您更輕松、方便的完成工作,大大減輕您的勞動強度.

        LA手扳葫蘆
        Model/Rated capacity 3/4TON 1 TON 1 1/2 TON W33 TON S3 TON 6 TON
        L   i    f    t (m) 1.5 1.5 1.5 1.5 1.5 1.5
        Mimimum distance between hooks (mm) 300.0 325.0 380.0 495.0 450.0 625.0
        Handle length(from pinion center ) (mm) 300.0 300.0 300.0 300.0 400.0 400.0
        H a n d l e   e f f o r t (kg) 15.0 21.0 16.0 17.0 21.0 23.0
        Net weight (kg) 6.5 7.0 10.0 16.0 18.0 32.0
        Gross weight (kg) 7.0 7.5 10.7 16.9 19.2 33.8
        A (mm) 300.0 325.0 380.0 495.0 450.0 625.0
        B (mm) 21.0 23.0 27.0 35.0 35.0 50.0
        C (mm) 22.0 24.5 26.0 29.0 29.0 49.0
        D (mm) 300.0 300.0 300.0 300.0 400.0 400.0
        E (mm) 154.0 154.0 176.5 176.5 211.5 211.5
        F (mm) 49.0 49.0 74.0 74.0 93.5 93.5
        G (mm) 105.0 105.0 102.0 102.5 118.0 118.0
        H (mm) 46.5 46.5 60.0 60.0 75.0 75.0
        I (mm) 57.0 67.0 82.0 126.0 93.0 168.0
        J (mm) 103.5 113.5 142.0 186.0 168.0 243.
        上一產品:DC手扳葫蘆
        下一產品:DA手板葫蘆
        產品系列
        公司資訊
        產品小知識
        聯系方式
        China Shanxi Taiyuan North Jiefang Road, Longcheng commercial building
        中國·山西 太原市解放北路龍城商務大廈
        Tel: +86 (351) 2303330 2992000
        Fax: +86 (351) 3188366
        E-mail: sxjyh@126.com
